Drains Unlimited Linear Drain With Triple-Side Return Flange

Description

Drains Unlimited DUFR-TF Linear Floor Drain with Three-Side Return Flange

The DUFR-TF Series of linear drains is designed to meet the classic appeal of traditional linear drains with the added benefit of a close-wall installation. The innovative wall-mounted design eliminates the tile strip between the back wall and the drain, typically requiring bonding the waterproofing or floating the finish tile for the same aesthetic appeal.

Features

• DUFR-TF Drain Grates are available in 3 different styles with 3 different finishes
• The Three Side Return Flange is ideal for wall-to-wall installations with 1/8″ to 3/8″ thick wall tiles
• Made from heavy-duty 304 stainless steel
• Textured flange ensures a tight waterproof membrane seal between the flange and membrane
• Removable grate for easy cleaning and maintenance
• Single slope to drain
• 2-7/16in (61.13mm) outlet size
• Excellent corrosion resistance
• Shallow V-bottom design for better water flow to the drain outlet
• SANS10400 compliant 75mm water seal
• Textured flange to ensure a tight waterproof membrane seal to the drain body
• ***Full length measured between finish face of framing

Suitable Substrates

• Concrete
• Exterior glue
• Plywood (Interior only)
• Cement backer board
• Cement mortar bed
• Shower pans

What’s included

• Drain Body
• Select Grate
• Two (2) Strainers
• Grate Hook
