Description
Norton Clipper C1320P 20″ Walk Behind Push Saw
Small to medium contractor work demands performance with an economical solution. The C1320P brings the contractor the ideal saw with a heavy-duty box frame that resists bending and supported with the high-performing Honda 13 HP engine. Heavy frame also provides a straighter cut. Changing or adjusting belts is simple with the single screw tensioner. The C1320P is in a class by itself.
Features
- Spindle-Saver blade flanges allows blade to sit on inner flange instead of shaft for replacement of flange only instead of complete shaft
- Four V-Belts transferring maximum power to the blade shaft
- Reinforced frame and axle strongest in its class
- Four stage Honda cyclone air filter
- Honda GX390, Single Cylinder 4 Cycle
- Screw feed blade depth control
- Maximum Saw Length (Working): 114″ (2,896 mm)
- Maximum Pointer Length: 40″ (1,016 mm)
- Frame Width (mm) 17″ (432 mm)
- Front (Outside to Outside Wheel Width) 14-3/16″ (360 mm)
- Rear (Outside to Outside Wheel Width) 15-1/4″ (388 mm)
- Blade to Wall 2-9/16″ (65 mm)
- Wheel Base Length 16-1/6″ (407 mm)
- 20″ Blade is sold separately
| Norton Clipper C1320P Walk Behind Push Saw Specifications | |
| Power (Gas) | 13 hp / 9.5 kW |
| Engine | Honda GX390 |
| Starter | Manual |
| Blade Capacity | 20 in |
| Blade Shaft RPM | 2,520 RPM |
| Arbor | 1 in |
| Depth of Cut | 7-5/8 in |
| Fuel Capacity | 1.79 gal (6.5 L) |
| Dimensions | 56 x 26 x 40 in |
| Weight | 310 lbs |
