Description
Raimondi Gladiator Advance Wet Tile Saw
Raimondi’s high-quality, belt-driven Gladiator rail saw offers professional-grade work when cutting granite, marble, porcelain, single and double-fired bricks, cement, etc.
Features
- Straight, 45° bevel (Jolly) and plunge cuts
- Rail pivots to a variety of angles for a perfect miter cut
- Optional collapsible table extensions on both sides
- Legs fold into the bottom of the water pan for ease of transporting
- Cast and extruded aluminum framework
- Easy-to-remove polypropylene 10-gallon tank for easy cleaning
- Aluminum cutting tables
- Floating blade guard
- Heavy-duty water pump and (2) jet nozzles (front or rear mounted)
- Sliding motor assembly with cast aluminum housing
- Material hold-down guide, rolling table extension, and extension side square are sold separately
What’s Included?
- Raimondi Gladiator Advanced Rail Saw
- Built-In Stand (with Wheels)
- 10 in G Slot Diamond Blade
- 45°/90° Sliding Square
- Dressing Stone
- Water Pump
- Wrench Kit
- Operator’s manual
| Raimondi Gladiator Specifications | |||
| Raimondi | Gladiator 85 | Gladiator 105 | Gladiator 130 |
| Voltage | 110V | 110V | 110V |
| Power | 1.5 hp | 1.5 hp | 1.5 hp |
| Draw | 20/25A | 20/25A | 20/25A |
| Blade RPM | 3600 | 3600 | 3600 |
| Blade Capacity | 10 in, 5/8 in arbor | 10 in, 5/8 in arbor | 10 in, 5/8 in arbor |
| Depth of Cut | 3 in | 3 in | 3 in |
| Length of Cut | 34 in | 41 in | 51 in |
| Diagonally Cuts | 24 in x 24 in Tile | 29 in x 29 in Tile | 35 in x 35 in Tile |
| Weight | 132 lbs. | 141 lbs. | 172 lbs. |
| LxWxH | 50 in x 27 in x 31 in | 57 in x 27 in x 31 in | 68 in x 27 in x 31 in |
| Shipping | Truck on Pallet | Truck on Pallet | Truck on Pallet |
