Description
Rubi DS-250-N Stone Saw with Laser and Level
Stone, ceramic tiles, and all types of building materials, such as brick, face brick, fire brick, etc.
Introducing the ZERO DUST System
Rubi has created a dust and water collection system per the construction industry’s health and dust prevention regulations. Zero dust technology drastically reduces airborne dust and water slurry, which prevents ailments related to inhaling silica dust. With this goal in mind, all RUBI DC, DS, DX, and DR tile and stone saws will include the standard ZERO DUST dust reduction system. The system also minimizes water consumption during the cutting process, reducing the tank’s time to refill.
Features
- Free Rubi 10″ diamond blade, 1″ arbor
- Rail pivots to a variety of angles for a perfect miter cut
- Thermal protection against current overload
- Mixed modular structure in aluminum and steel for maximum lightness and resistance
- Motor assembly mounted on sliding bearings.
- Retractable legs with a “œshield” function and a wheeled transportation system
- Aluminum guide with anti-bend geometry
- Measuring guide and lateral stops for longitudinal cut
- Detachable working surface for easy cleaning
- Water pump with flow control valve for cooling the diamond blade
- Removable plastic water pan for easy cleanup
What’s Included?
- Rubi DS250 Rail Stone Saw
- Saw Stand with Wheel Kit and Handles
- 10 in. Diamond blade, 1 in Arbor
- Water Pump
- Water Trays
- Laser and level
- Cord
- Operator’s manual
| Rubi DS-250 Rail Saw Specifications | ||||
| Model | 52934 | 52944 | 52936 | 52946 |
| Power (Direct Drive) | 3 hp/25 amps | 3 hp/25 amps | 3 hp | 3 hp |
| Voltage | 120V | 120V | 220V | 220V |
| Blade RPM | 2800 | 2800 | 2800 | 2800 |
| Length of Cut | 52 in | 132 cm | 59 in | 152 cm | 52 in | 132 cm | 59 in | 152 cm |
| Diagonal Cut | 36 in | 42 in | 36 in | 42 in |
| Blade Capacity | 10 in | 10 in | 10 in | 10 in |
| Arbor | 1 in | 1 in | 1 in | 1 in |
| Depth of Cut | 2-1/16 in | 2-1/16 in | 2-1/16 in | 2-1/16 in |
| Weight | 227 lbs | 234 lbs | 227 lbs | 234 lbs |
