Rubi Slim Easy Trans Plus Tile Alignment System

Description

Rubi Slim Easy Trans Plus

The Slim Easy Trans Plus has been designed for handling large porcelain sheets thanks to the retractable reinforced aluminum profile system, which can handle up to a maximum length of 10.4 ft (320cm) with a maximum thickness of .23 inches (6mm). These retractable profiles can be adjusted in height from 5.5 ft to 10.4 ft.

Features

• Safe, practical, and light
• Designed to handle large porcelain tiles
• Two reinforced aluminum guides, retractable and adjustable from 5.5 ft to a maximum of 10.4 ft (170 to 320 cm)
• The optimal recommended distance between handles is 70 cm
• 6 interchangeable 20 cm diameter vacuum suction cups
• Suction cups can be positioned anywhere along the guide, providing versatility
• Highly reinforced steel handles can be adjusted along the guide to facilitate tile placement
• Anti-rotation system and Soft-grip handles allow safe transport and handling of the set (the handles can be removed if needed)
• The guides can be used individually
• In the case of transporting long and narrow strips, the load capacity of a single bar would be reduced by half
• Load capacity of 176 lbs (80kgs)
• ***Adding more suction cups does not increase the maximum load capacity
